HK Makine, based in Gaziantep, manufactures industrial cooling systems with open circuit, closed circuit, package type and mini water cooling tower models. 15 standard models compliant with CTI standards, custom manufacturing and service across all 81 provinces of Turkey.
A water cooling tower is industrial heat recovery equipment that expels waste heat from process water to the atmosphere via evaporation and convection, then returns the cooled water to the system.
CTI (Cooling Technology Institute) Standards: HK Makine designs all models according to CTI performance, safety and environmental standards — ensuring measurable capacity guarantees on every delivered system. All key components — cooling tower fill media (film-type PVC), cooling tower nozzle system and cooling tower fan motor — are manufactured with domestic quality assurance.
The fundamental choice in industrial cooling systems is between open circuit water cooling tower and closed circuit water cooling tower. A package type cooling tower and a mini water cooling tower (HK17) are also available for smaller capacities.
Not sure which system to choose? Share your process fluid, water analysis and operating temperatures. Our engineers determine the most suitable system free of charge: +90 536 037 3281
International-standard design and manufacturing
Minimum evaporation loss with film fill
Balanced fan motor — below 55 dB(A)
20% savings with inverter option
Installation, commissioning and maintenance
Project-based manufacturing beyond standard models
Fast spare parts and delivery
Water treatment consultancy included
High mechanical durability in heavy industry. Special epoxy coating for corrosion protection. Most economical and widely preferred choice.
Sustainable rust protection in intensive industrial environments. Balanced cost-durability between black steel and stainless steel.
Stainless steel cooling tower — first choice for food, pharmaceutical and chemical industries. AISI 316L for seawater environments. Lifetime corrosion-free guarantee.
Correct cooling tower selection requires calculating your heat load first. Wrong capacity selection causes energy waste and production losses.
Heat Load Calculation Formula:
From HK17 to HK65, 40,000–2,500,000 kcal/h — 15 standard models for every industrial facility. Select the model 20% above your cooling tower capacity calculation result.
Scroll the table left and right to view all columns
| MODEL | Capacity (kcal/h) | Flow (m³/h) | Empty Wt. | Full Wt. | Fan Dia. (mm) | Motor (kW) | Pressure (mmWC) |
|---|---|---|---|---|---|---|---|
| HK 17 | 40,000 | 5–8 | 130 kg | 303 kg | 550 | 0.75 | 1,550 |
| HK 19 | 65,000 | 7–12 | 180 kg | 420 kg | 600 | 1.1 | 1,650 |
| HK 21 | 90,000 | 9–18 | 298 kg | 537 kg | 750 | 1.1 | 1,700 |
| HK 23 | 115,000 | 12–22 | 345 kg | 719 kg | 800 | 1.5 | 1,720 |
| HK 25 | 140,000 | 15–28 | 347 kg | 721 kg | 900 | 2.2 | 1,750 |
| HK 30 | 300,000 | 30–60 | 603 kg | 1,183 kg | 1,000 | 3 | 2,200 |
| HK 33 | 450,000 | 45–90 | 835 kg | 1,753 kg | 1,200 | 4 | 2,500 |
| HK 35 | 600,000 | 60–120 | 1,160 kg | 2,488 kg | 1,200 | 5.5 | 2,600 |
| HK 37 | 850,000 | 85–170 | 1,176 kg | 2,336 kg | 1,200×2 | 5.5×2 | 2,800 |
| HK 40 | 1,100,000 | 110–220 | 1,642 kg | 3,476 kg | 1,200×2 | 5.5×2 | 3,100 |
| HK 45 | 1,350,000 | 135–270 | 2,250 kg | 4,946 kg | 1,200×3 | 5.5×3 | 3,300 |
| HK 50 | 1,600,000 | 160–320 | 3,420 kg | 7,404 kg | 1,200×3 | 7.5×3 | 3,500 |
| HK 55 | 1,850,000 | 185–370 | 3,800 kg | 8,200 kg | 1,400×3 | 11×3 | 3,700 |
| HK 60 | 2,100,000 | 210–420 | 4,200 kg | 9,100 kg | 1,400×4 | 11×4 | 3,900 |
| HK 65 | 2,500,000 | 250–500 | 4,800 kg | 10,500 kg | 1,600×4 | 15×4 | 4,200 |
| Standard test conditions: Inlet 37°C, outlet 32°C, wet bulb 24°C. Custom manufacturing available for capacities above 2,500,000 kcal/h. +90 536 037 3281 | |||||||
Cooling tower prices vary by capacity, body material, system type and additional options. HK Makine offers solutions for every budget.
15 price tiers from HK17 (40,000 kcal/h) to HK65 (2,500,000 kcal/h). Custom pricing for higher capacities.
ST37 (economic) — Galvanized (mid-range) — Stainless Steel AISI 304/316 (premium).
Open/closed circuit, inverter drive, automation panel, remote monitoring determine the final price.
Delivery to all 81 provinces of Turkey. Assembly, commissioning and pipe connection included in offer price.
We calculate a personalised price based on your capacity and material selections — completely free.
Regular cooling tower maintenance and a correct water treatment programme are essential for efficiency, long service life and Legionella prevention.
Fan motor current and noise check, water basin level, nozzle blockage check, pH and conductivity measurement, belt tension adjustment, fill media cleaning.
Anti-scalant, corrosion inhibitor and biocide chemical programme is mandatory. Regular disinfection required between 25–45°C.
Fill media, fan motor, bearing and belt inspection/replacement. HK Makine offers 2–4 visits per year + emergency service guarantee across all 81 provinces.
Important Note: HK Makine manufactures only brand-new water cooling towers. We do not sell second-hand products.
